Mutoh 1638 CR Speed Reduction Belt DF-43940

price: 29.95USD [wp_cart:Mutoh 1604 CR Speed Reduction Belt DF-43940:price:29.95:end]

Mutoh 1638 CR Speed Reduction Belt DF-43940

has a circumference of 240mm and is 10mm wide. original Mutoh part number DF-43940.

This Mutoh CR Belt can be used for the following printers:

Mutoh Valuejet 1604. Valuejet 1614. Valuejet 1608 Hybrid. Valuejet 1604W. 1624. 1638.
Mutoh Osprey 75. Osprey 102.
Blizzard 65. Blizzard 90.
RJ-8000-50 (Falcon II). RJ-8000-64 (Falcon II). RJ-8000-87 (Falcon II).
Rockhopper II-2H. Rockhopper II-4H. Rockhopper II 50. Rockhopper II 64. Rockhopper II 87.
Rockhopper 3 65. Rockhopper 3 90. Rockhopper 3 Extreme 65. Rockhopper 3 Extreme 90.
Spitfire 65. Spitfire 90. Spitfire 100 Extreme.
Toucan 64 4 colours. Toucan 64 6 colours. Toucan 87. Toucan Hybrid.
Viper 100. Viper 100 TX Extreme. Viper 65. Viper 90. Viper TX 65. Viper TX 90.
Viper Extreme 65. Viper Extreme 90. Viper TX Extreme 65. Viper TX Extreme 90.

7.6 CR Speed Reduction Belt Tension Adjustment This section describes the procedure to adjust the tension of the CR speed reduction belt. When you have removed and installed the CR speed reduction belt, adjust the CR speed reduction belt tension. 7.6.1 Jigs and Tools The jigs and tools required for CR speed reduction belt tension adjustment are as follows. • Tension gauge: for measuring Max. 40N (4080gf) “8.4 Jigs and Tools” p.8-6 7.6.2 Adjustment Procedures 1. Remove the side maintenance cover L. “4.2.5 Removing Side Maintenance Cover L” p.4-12 2. Remove the side top cover R. “4.2.6 Removing Side Top Cover R” p.4-12 3. Remove the panel to conversion board tape wire from the flat cramps (2 pieces) on the back of the cartridge cover stay. No. Part name 1 CR motor assembly 2 Cartridge cover stay 3 Panel to conversion board tape wire 4 Flat cramp 1 3 2 4 7 Adjustment VJ-1604 Maintenance Manual Rev.-00 7-28 4. Remove the screws (3 pieces) that retain cartridge cover stay R. 5. Remove the cartridge cover stay R. 6. Loosen the hexagon bolts (4 pieces) that retain CR motor mounting plate. No. Part name 1 CR motor assembly 2 Cartridge cover stay R 3 Screws that retain cartridge cover stay R (pan-head screw with spring washer and flat washer M4 × 8) No. Part name 1 CR motor assembly 2 Cartridge cover stay R 3 Screws that retain cartridge cover stay R (pan-head screw with spring washer and flat washer M4 × 8) 3 2 1 2 3 Upper Lower 1 2 2 3 VJ-1604 Maintenance Manual 7 Adjustment 7-29 Rev.-00 7. Mount a tension gauge to CR motor mounting plate. 8. Pull the tension gauge in a direction perpendicular to CR motor assembly so that the tension of the CR speed reduction belt equals the specification. TIP The tension specification of the CR speed reduction belt is 34.32N ± 3.42N (3,500gf ± 350gf). 9. Tighten the hexagon bolts (4 pieces) that retain the CR motor mounting plate. 10. Continue adjusting until the tension of the CR speed reduction belt equals the specification. 11. Remove the tension gauge from the CR motor mounting plate. 12. Close all the covers.
