Description
This Electronic Ballast FEB12-50 is for MH 20 W to 150Ｗ
For Metal Halid Lamps
Power Factor: >=0.97
Frequency: 50/60Hz
Harmoic Total <=0.1
Max temperature: 80 C
Working Temperature: -20~+50C
Peak Voltage: 3.5~4.5 KV
Caution: Disconnect power before service!
Do not connect lamp leads to neutral!
Ballast case mustr be grounded by green lead wire!
Max ballast lamp distance 3m!
Electronic Ballast FEB12-50 specifications:
Type: FEB12-50
Lamp Power:50 Watts
Input Power: 50 Watts
Input Voltage: 95~145 V
Input Current: <=0.52 Amp
Circuit Power Factor: >=0.97
Lamp Rated Current: 0.76 Amp
Lamp Starting Current: <=0.90 Amp
Output Voltage: 400 V
