Electronic Ballast FEB22-35X2

$55.93

Electronic Ballast FEB22-35X2

SKU: Electronic Ballast FEB22-35X2 Categories: , Tag:

Description

This Electronic Ballast FEB22-35X2 is for MH 20X2 W 35X2 W 70X2 W
For Metal Halid Lamps
Power Factor: >=0.97
Frequency: 50/60Hz
Harmoic Total <=0.1 Max temperature: 80 C Working Temperature: -20~+50C Peak Voltage: 3.5~4.5 KV Caution: Disconnect power before service! Do not connect lamp leads to neutral! Ballast case mustr be grounded by green lead wire! Max ballast lamp distance 3m! Electronic Ballast FEB22-35X2 specifications: Type: FEB22-35X2 Lamp Power:35X2 Watts Input Power: 35X2 Watts Input Voltage: 175~277 V Input Current: <=0.37 Amp Circuit Power Factor: >=0.97
Lamp Rated Current: 1.2 Amp
Lamp Starting Current: <=0.80 Amp Output Voltage: 400 V
