IKO METC-15-SL Bearing Block

Description

IKO METC-15-SL Bearing Block

How to install IKO METC-15-SL Bearing Block?

Loose or Tight the screws of IKO METC-15-SL Block marked yellow to adjust the tension between block and linear rail.

1. Must cleaning your IKO METC-15-SL rail perfect because a little durst can cause to fail to install.
2. Put lubricating oil on the IKO METC-15-SL Block rail.
3. Must be keep perfect alignment to install the IKO METC-15-SL Block. In some case, no enough space to install IKO METC-15-SL Block and you need to uninstall the rail to install it.
4. Loose 4 screws to let the IKO METC-15-SL Block can go to the rail easily.
5. Put IKO METC-15-SL Block gently to the rail and sliding slowly the whole block.
6. Then tight the IKO METC-15-SL Block’s screws correct to keep the IKO METC-15-SL Block perfect to fit the rail.

This IKO METC-15-SL Bearing Block Has the following specifications:

Size: 15

Block Weight: 0.11 kg

Rail Weight: 1.57 g/100 mm

H: 24 mm

H1: 5.8 mm

N: 18.5 mm

W2: 52 mm

W3: 41 mm

W4: 5.5 mm

L1: 41 mm

L2: mm

L3: 22.4 mm

L4: 45 mm

M1: M5 mm

D1: mm

H2: 7 mm

H3: 4.5 mm

W: mm
