Description
THK HSR15YR1SS Block
This THK HSR15YR1SS Block is for all machines that use this block.
THK HSR15YR1SS Block eliminates the friction between the ball and increase the grease retention, in order to achieve low noise, high speed and long maintenance-free operation.
THK HSR15YR1SS Block Specifications:
ID: HSR15YR1SS
Size: 15
Type: Tapped Holes on Side
Preload: No Preload
Height M: 28
Width W: 33.5
Length L: 56.6
B: 11.5
C: 18
S: M4X5
Pitch F: 60
d1*d2*h: 4.5×7.5×5.3
Dynamic Rating C: 10.90
Static Rating C0: 15.70
Weight:Â 0.2 kg
