Description
THK HSR20LA1SS Block
This THK HSR20LA1SS Block is for all machines that use this block.
THK HSR20LA1SS Block eliminates the friction between the ball and increase the grease retention, in order to achieve low noise, high speed and long maintenance-free operation.
THK HSR20LA1SS Block Specifications:
ID: HSR20LA1SS
Size: 20
Type: Narrow Tapped Holes
Preload: No Preload
Height M: 30
Width W: 63
Length L: 74
B: 53
C: 40
S: M6
Pitch F: 60
d1*d2*h: 6×9.5×8.5
Dynamic Rating C: 19.80
Static Rating C0: 27.40
Weight:Â 0.47 kg
