Description
THK HSR35R1SS Block
This THK HSR35R1SS Block is for all machines that use this block.
THK HSR35R1SS Block eliminates the friction between the ball and increase the grease retention, in order to achieve low noise, high speed and long maintenance-free operation.
THK HSR35R1SS Block Specifications:
ID: HSR35R1SS
Size: 35
Type: Narrow Tapped Holes
Preload: No Preload
Height M: 48
Width W: 100
Length L: 109.4
B: 82
C: 62
S: M10
Pitch F: 80
d1*d2*h: 9x14x12
Dynamic Rating C: 53.90
Static Rating C0: 70.20
Weight: 2 kg
