Temperature Controller

$79.02

Temperature Controller

Temperature Controller is for External UV Printhead Heater. You can save big money with this Temperature Controller because you can use solvent printhead instead of uv printhead. Just install this standalone heater system for printhead.

Description

Temperature Controller

This Temperature Controller Dimension is 60*45*31 mm.

  1. Technical Parameters
  2. Temperature range: -50 ~ 110
  3. Measurement accuracy: 0.2% FS
  4. Temperature control accuracy: 0.1 ℃
  5. Refresh rate: 0.5 S
  6. Input power:    12VDC 24VDC 220VAC
  7. Output power: 12VDC 24VDC 220VAC
  8. Measurement input: NTC (B3950 = 10K 0.5%) 1 meter waterproof sensor
  9. Output Current: Max 10A
  10. Environmental requirements: -30 ~ 60 ℃
  11. Humidity 20% -85%
  12. Dimension: 60 * 45 * 31 mm
  13. Distance between two screws’ holes: 73 mm
